Set of two lenses | dedicated to the H1 filament

set of bi-xenon lenses for self-assembly

• The lenses have a diaphragm controlled by an electromagnet that changes the range of illumination of the lights - low beam -> high beam
• The light source in the lenses can be an H1 xenon bulb or an H1 LED bulb

A set of lenses for professional conversion of reflector lamps into lens lamps. The presented set of bi-xenon lenses for self-assembly allows you to perform the so-called retrofit . This is an ideal solution for people who have lamps made with reflector technology (without a lens) and who want to enjoy the advantages of xenon light without blinding other road users.

Installing the lens involves inserting the lens body into the bulb hole on the side of the lamp shade and locking it in the lamp using H7 or H4 adapters. The adapters are installed in a similar way to the way a regular bulb is installed in a lamp.

The set includes:

• 2 bi-xenon lenses (with electromagnet-controlled diaphragm) using commonly available H1 bulbs
• 2 adapters for mounting decorative covers
• 2 decorative covers (so-called grilles, bezels) to choose from from the 8 designs below.
• adapters for installation in the H7 or H4 socket
• mounting elements (rubbers and rings allowing the lens to be mounted in the lamp)

Lens dimensions:

Lens installation is possible in lamps factory equipped with an H7 or H4 bulb and does not require cutting or gluing and is fully reversible. In order to perform a retrofit, the lamp must be disassembled/disassembled. Then we place the lens module on the reflector side and secure it in the reflector socket using the included adapters. The included rubber gaskets and retaining rings securely mount the lens to the headlight. Then simply reassemble/glue the lamp. By placing the lens in the original socket, the standard lamp adjustment method is maintained and the lens itself is properly leveled.

We leave the cover pattern on the lenses to your choice. The appearance of our covers was inspired by the design of factory lenses of leading European car brands:

Advantages of our lens sets:

• high quality of optical elements
• simple assembly
• use of the popular H1 filament
• compact dimensions of the lens module allowing installation even in small headlights (e.g. motorcycles)
• perfect light distribution
• light-shadow cut-off line as in factory xenon headlights - no dazzling other drivers
• built-in electromagnet controlling the change of headlights from low beam to high beam
• possibility of selecting an aesthetic cover for virtually any type of lamp
